Dell OptiPlex 5060 – SFF – Core i5 8500 3 GHz – 8 GB – 256 GB

Dell OptiPlex 5060 – SFF – 1 x Core i5 8500 / 3 GHz – RAM 8 GB – SSD 256 GB – Class 20 – DVD-Writer – UHD Graphics 630 – GigE – Win 10 Pro 64-bit – monitor: none – BTS

Chassis / Form Factor: Desktop slimline

Dimensions & Weight / Depth: 29.2 cm

Dimensions & Weight / Height: 29 cm

Dimensions & Weight / Width: 9.26 cm

Display / Type: None.

Hard Drive / Capacity: 256 GB

System / Hard Drive Capacity: 256 GB

Header / Brand: Dell

RAM / Installed Size: 8 GB

Mainboard / Chipset Type: Intel Q370

Miscellaneous / Product Color: Black

Networking / Data Link Protocol:

• Ethernet

• Fast Ethernet

• Gigabit Ethernet

OS Provided / Type: Windows 10 Pro 64-bit Edition

Optical Storage / Drive Type: DVD-Writer

Optical Storage / Type: DVD-Writer

Packaged Quantity: 1

Processor / Generation: 8

Processor / Manufacturer: Intel

Processor / Number of Cores: 6-core

Processor / Processor Number: I5-8500

Processor / Clock Speed: 3 GHz

Processor / Type: Core i5

RAM / Data Integrity Check: Non-ECC

RAM / Form Factor: DIMM 288-pin

RAM / Max Supported Size: 64 GB

RAM / Memory Speed: 2666 MHz

RAM / Technology: DDR4 SDRAM

Service & Support / Type: 3-year warranty

System / Type: Personal computer

Video Output / Graphics Processor: Intel UHD Graphics 630

Dimensions & Weight / Weight: 5.26 kg

General

Type: Personal computer

Product Form Factor: Small form factor

Built-in Devices: Speaker

Embedded Security: Trusted Platform Module (TPM 2.0) Security Chip

Processor / Chipset

CPU: Intel Core i5 (8th Gen) 8500 / 3 GHz

Max Turbo Speed: 4.1 GHz

Number of Cores: 6-core

CPU Qty: 1

Max CPU Qty: 1

Processor Main Features: Intel Turbo Boost Technology 2

Chipset Type: Intel Q370

Cache Memory

Installed Size: 9 MB

Cache Per Processor: 9 MB

RAM

Installed Size: 8 GB / 64 GB (max)

Technology: DDR4 SDRAM – non-ECC

Effective Memory Speed: 2666 MHz

Rated Memory Speed: 2666 MHz

Form Factor: DIMM 288-pin

Slots: 4 (total) / 2 (empty)

Configuration Features: 2 x 4 GB

Hard Drive

Type: SSD – M.2

Capacity: 1 x 256 GB

Interface Type: SATA

Features: Class 20

Storage Controller

Type: 1 x SATA

Controller Interface Type: SATA 6Gb/s

Optical Storage

Type: DVD-Writer

Monitor

Monitor Type: None.

Graphics Controller

Graphics Processor: Intel UHD Graphics 630

Video Interfaces: DisplayPort

Audio Output

Speakers Included: 1 x mixed channel

Input Device

Type: Mouse (on selected markets only), keyboard (on selected markets only)

Keyboard

Keyboard Name: Dell KB216 Wired Keyboard

Mouse

Mouse Name: Dell MS116 USB Optical Mouse

Technology: Optical

Interface: USB

Networking

Ethernet Controller: Intel I219-V

Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet

Features: Remote Wakeup, PXE support

Expansion / Connectivity

Bays:

• 1 (total) / 0 (free) x external 5.25″ Slim Line

• 1 (total) / 1 (free) x internal 3.5″

• 2 (total) / 2 (free) x internal 2.5″

Slots:

• 1 (total) / 1 (free) x PCIe 3.0 x16

• 1 (total) / 1 (free) x PCIe 3.0 x4

• 1 (total) / 0 (free) x M.2 Card – 2280/2230

• 1 (total) / 1 (free) x M.2 Card – 2230

Interfaces:

• 5 x USB 3.1 Gen 1 (1 in front)

• 2 x USB 2.0 (2 in front) (PowerShare)

• 1 x USB-C 3.1 Gen 2 (1 in front)

• 1 x headphones/microphone (1 in front)

• 1 x audio line-out (1 rear)

• 1 x LAN (Gigabit Ethernet)

• 2 x DisplayPort

• 2 x USB 2.0 (2 rear) (supports SmartPower On)

Miscellaneous

Theft/Intrusion Protection: Security lock slot (cable lock sold separately), padlock loop, chassis intrusion switch

Security Slot Type: Kensington security slot

Pricing Type: Build To Stock (BTS)

Power

Device Type: Power supply

Nominal Voltage: AC 120/230 V (50/60 Hz)

Power Provided: 200 Watt

80 PLUS Certification: 80 PLUS Bronze

Efficiency: 85%

Operating System / Software

OS Provided: Windows 10 Pro 64-bit Edition

Software: Microsoft Office (30 days trial), CyberLink Media Suite Essentials

Environmental Standards

ENERGY STAR Certified: Yes

ENERGY STAR Version: 6.1

Manufacturer Warranty

Service & Support: Limited warranty – 3 years – on-site

Dimensions & Weight

Width: 9.26 cm

Depth: 29.2 cm

Height: 29 cm

Weight: 5.26 kg

Dimensions & Weight (Shipping)

Shipping Width: 48.7 cm

Shipping Depth: 39.4 cm

Shipping Height: 26.4 cm

Shipping Weight: 6.45 kg
